15 kW Hybrid Inverter + 15 kWh BESS

Name: 15 kW Hybrid Inverter + 15 kWh BESS
Brand: SURIN INTERNATIONAL PVT. LTD.
Price: 470000.0 INR
Availability: InStock

Price 470000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

15 kW Hybrid Inverter + 15 kWh BESS Specification

Maintenance Type
Low Maintenance

Features
Remote Monitoring, Touchscreen Display, Inbuilt MPPT, Anti-islanding Protection, Load Management, Wi-Fi/RS485/Ethernet Connectivity

Input Voltage
150V-900V DC

Efficiency
>97%

Product Type
Hybrid Inverter + Battery Energy Storage System (BESS)

Material
Metal Body with Advanced Electronic Components

Number of Cells
Customized as per battery configuration (nominal 48 cells)

Power
15 kW

Operating Temperature
-20C to 60C

Max Voltage
900V DC

Max System Voltage
1000V DC

Output Voltage
230V/400V AC

Cable Length
Customizable as per requirement

Switch Mode
Automatic/Manual Switch

Size
Standard Compact Modular Design

Dimension (L*W*H)
1050 x 600 x 320 mm (approx.)

Color
White and Blue

Weight
165 kg (inverter) + 200 kg (BESS) approx.

Application
Residential, Commercial, Industrial, Microgrid

Type Of Technology
Hybrid Technology - Solar/Grid/DG Integration

Installation Type
Floor Mounted / Wall Mounted

Charge/Discharge Rate
0.5C / 1C

Cycle Life
>6000 cycles @ 80% DOD

Grid Type
On-grid/Off-grid/Hybrid Mode

Communication Interface
Wi-Fi, RS485, CAN, Ethernet

Display
LCD Touchscreen

Battery Capacity
15 kWh Li-ion/LFP

Protection Features
Overload, Short Circuit, Over/Under Voltage, Surge, Reverse Polarity, Battery Management System (BMS)

Cooling Method
Smart Forced Air Cooling

Rated Output Frequency
50/60 Hz

Noise Level
<50 dB

About 15 kW Hybrid Inverter + 15 kWh BESS

Ensure zero downtime for your large home or workspace. This robust inverter and storage combo is designed to power up to 3 ACs, 2 refrigerators, and all your lighting needs. Providing 3 hours of backup power, this system protects your sensitive appliances and keeps your environment comfortable during unexpected failures.

Versatile Hybrid Energy Solution

Designed to integrate solar, grid, and diesel generators seamlessly, this hybrid inverter system ensures continuous power supply and optimal energy management. Its flexible operation modes support both on-grid and off-grid scenarios, making it suitable for varied energy demands in households, businesses, or microgrids.

Advanced Protection and Longevity

Safety and durability are prioritized with multiple protections including overload, short circuit, over/under voltage, surge, reverse polarity, and comprehensive battery management (BMS). The smart forced air cooling and modular metal construction maintain system integrity in temperatures ranging from -20C to 60C, extending the life and performance of the battery system.

Effortless Operation and Monitoring

An intuitive LCD touchscreen and remote connectivity through Wi-Fi, RS485, CAN, or Ethernet make controlling and monitoring your energy system straightforward. Inbuilt MPPT, anti-islanding, load management, and customizable cable lengths further simplify installation, operation, and ongoing maintenance.

FAQ's of 15 kW Hybrid Inverter + 15 kWh BESS:

Q: How is the 15 kW Hybrid Inverter + 15 kWh BESS installed and where can it be placed?

A: This system is designed for flexible installation, supporting both floor-mounted and wall-mounted setups to suit diverse application spaces. Its compact modular design allows it to fit in utility rooms, basements, garages, or dedicated equipment areas, suitable for residential, commercial, or industrial environments.

Q: What are the main benefits of using a hybrid inverter with lithium or LFP batteries?

A: Employing a hybrid inverter with Li-ion or LFP batteries ensures high efficiency (>97%), long cycle life (>6000 cycles at 80% DOD), and robust safety features. This results in lower maintenance, reduced energy costs, reliable backup during outages, and the ability to maximize renewable energy usage.

Q: How does the system switch between grid, solar, and generator power sources?

A: The hybrid inverter features automatic and manual switching modes. It intelligently prioritizes solar, then grid, and finally diesel generator input, ensuring seamless power delivery based on availability and demand, making energy management effortless and reliable.

Q: What kind of monitoring and control options are available?

A: Users can monitor and control the system both locally via the LCD touchscreen and remotely using Wi-Fi, RS485, CAN, or Ethernet communications. Remote monitoring enables real-time performance checks, diagnostics, and system adjustments from any location.

Q: When is maintenance required, and what does it involve?

A: Thanks to its low maintenance design, only basic periodic checks are necessary-mainly visual inspection of connections, ensuring airflow for cooling, and confirming firmware updates. The Battery Management System (BMS) and protective circuits reduce the need for frequent interventions.

Q: What type of protection features are built into the inverter and battery system?

A: The system incorporates multiple protection layers: overload, short circuit, over/under voltage, surge, reverse polarity, and comprehensive BMS. These features protect equipment from electrical faults and extend system life.
